   Products   Flatbed Scanners


300dpi Download


300dpi Download

Image Sensor CIS
Light Source LED
Optical Resolution 1200 dpi
Scan Modes Color: 48-bit input, 24-bit output
Grayscale: 16-bit input, 8-bit output
B/W: 1-bit output
Scanning Speed 5 sec (Color Mode, 300dpi, A3)
3 sec (Grayscale / B&W Mode, 300dpi, A3)
Scanning Area (W x L) Max. 297 x 431.8 mm (11.69" x 17")
Daily Duty Scan ( Sheets ) 2,500
Power Supply AC Power: 24 V / 0.75 A
Interface USB 2.0
Net Weight 4.32 Kgs (9.52 Lbs)
Dimensions (W x D x H) 589 x 407 x 68 mm (23.18” x 16.02” x 2.67”)
Protocol TWAIN Compliant
Operating System Windows 8 / 10 / 11
macOS 10.14 / 10.15 / 11.x / 12.x / 13.x / 14.x
Hardware Requirements Windows
2.4 GHz CPU processor or higher[1]
[1]Windows Recommended: 2.8 GHz Intel® Core™ i5 Processor with 4 CPU Cores or higher

4 GB RAM minimum (Recommended: 8 GB or more, A3 size@1200 dpi scanning, allocated 20 GB Virtual Memory at minimum)
6 GB of hard-disk space for program installation
Display dimensions of 1024x768 or greater
Bundled Software Plustek Image Express
Plustek DocTWAIN
Plustek ICA
Built-in OCR Plustek OCR (For Windows)
(Powered by ABBYY® FineReader®)
Plustek DocOCR (For Mac)
