The Perfect Assistant for Small Offices and Workgroup Users
The Plustek SmartOffice PL1500 is a cost-effective way that brings you to go paperless. The Plustek SmartOffice PL1500 is helpful to enhance work efficiency with 15ppm scan speed and the ADF feeder capacity of 50 pages. With the functionality of sheetfed and flatbed, it is easy for the staff to handle a lot of documents scan in different sizes. Documents digitalization, file sharing and management can be simplified by using the Plustek SmartOffice PL1500. This scanner is idealistic for small business units and distributed branch offices, especially with limited budgets. |
|
Single-Touch Function Buttons
With Single-Touch Function button design, the Plustek SmartOffice PL1500 allows you to complete scanning task with ease with just one touch of button. It includes five default buttons to access OCR, Copy, Searchable PDF and File, and these buttons can also be customized for your specific need. To be easily digitalized any documents in different sizes, it offers the features of auto-size, auto-crop and auto-deskew functions. Therefore, all documents can be instantly stored, reorganized, edited, and also remote sharing with group members. |
 |
 |
Ideal for Hi-resolution Photo Scanning
With the Plustek advanced CCD sensor technology, up to 1200 x 1200dpi optical resolution, it is very suitable for hi-resolution photo scanning with the outstanding scanning modes in 24-bit true color and 256 levels of grayscale as well as black-and-white modes. Improved color accuracy enhances images for much truer and more consistent colors. Therefore it can offer high depth of field and true color in graphic scanning needs. |
|
Environmentally Responsible and Energy-Saving
The SmartOffice PL1500 is ENERY STAR certified and environmentally responsible. |
 |
|
Features
The SmartOffice PL1500 has following features: |
|
|
● Auto Threshold
Automatically thresholds the current image into a binary black and white image.
|
 |
|
● Auto Rotate
Automatically rotates document based on the contents of the document.
|
 |
|
● Auto Crop & Deskew
Automatically straightens and crops image to the documents actual size.
|
 |
 |
● Color Dropout
Removes red, green or blue color when scanning forms. |
|
● Blank Page Removal
Automatically removes blank pages without manual editing. |
 |
| Optical Resolution | 1200 dpi |
| Hardware Resolution | Flatbed: 1200 x 1200 dpi ADF: 600 x 600 dpi |
| ADF Capacity | 50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs) Note: Maximum ADF capacity varies, depending upon paper weight. |
| Scanning Speed ( ADF ) | 8 ppm (Color mode, 200 dpi, A4 Portrait) 15 ppm (Grayscale mode, 200 dpi, A4 Portrait) 15 ppm (B&W mode, 200 dpi, A4 Portrait) Note : Results may vary depending upon your scanning application, computer processor and system memory. |
| Scanning Area (W x L) | Flatbed: Max. 216 x 297 mm (8.5" x 11.69") Min. 12.7 x 12.7 mm (0.5" x 0.5") ADF: Max. 216 x 356 mm (8.5" x 14") Min. 12.7 x 12.7 mm (0.5" x 0.5") |
| Acceptable Paper Sizes (W x L) | Flatbed: Max. 216 x 297 mm (8.5" x 11.69") Min. 12.7 x 12.7 mm (0.5" x 0.5") ADF: Max. 220 x 356 mm (8.66" x 14") Min. 90 x 114 mm (3.55" x 4.5") |
| Acceptable Paper Weight (Thickness) | 50 to 120 g/㎡ (14 to 32 Lbs) |
| Daily Duty Scan ( Sheets ) | 1,500 |
| Action Button | Scan, Copy, OCR, File, Custom |
| Power Supply | 24 Vdc/ 0.75 A |
| Net Weight | 4.8 Kgs (10.58 Lbs) |
| Dimensions (W x D x H) | Without Input tray: 468 x 347 x 175 mm (18.43" x 13.66" x 6.89") With input tray: 468 x 347 x 300 mm (18.43" x 13.66" x 11.81") |
| OS | Windows 2000 / XP / Vista / 7 / 8 |
| Hardware Requirements | Pentium IV 2.0 GHz processor or faster CPU CD-ROM Drive One available USB Port 512 MB RAM or higher recommended 800 MB free HDD space (1 GB or larger recommended)
|
ABBYY FineReader 6.0 Sprint Plus
Optical Character Recognition software with a simple user interface, supports recognition up to 177 languages and has the following features,
- Work with single or multi-page documents.
- Easily create searchable PDF, Microsoft Word, Microsoft Excel, TXT, HTML files.
- Convert paper documents to digital information.
Scan and read documents, and save in searchable PDF, Microsoft Word, Microsoft Excel, TXT, HTML files for editing, collaboration and sharing.
Supports recognition up to 177 languages.
Plustek DI Capture
Image capture and management software featured with indexed archives. Makes it easy manage and organize documents and images efficiently. Exports files in PDF, JPEG, TXT and XLS with flexible file naming options.
Videos:
Plustek DocAction
Button utility to simplify document scanning. DocAction enables you to specify your personalized scanning configuration settings and scan documents with the touch of a button. Scanned documents are automatically sent directly to Printer, Email, Folder or FTP. DocAction also enables you to scan directly to many imaging and document management applications. DocAction saves scanned documents in all common imaging formats including: JPEG, TIFF, and PDF.
Videos:
Set your preferences of advanced functions of Removal Blank Page, Image Edge Fill and Remove Punch Holes.
Plustek DI Express 6
Features accurate and efficient Optical Character Recognition (OCR) for four Asian languages: Traditional Chinese, Simplify Chinese, Japanese and Korean with automatic image processing functions such as Color-Dropout, Threshold, Rotating. Import images, or image PDF and convert to TXT, RTF, Searchable PDF, XLS formats, and editable text.
Import images, image PDFs or scan to input documents
Enhance documents with automatic image processing functions, including Color-Dropout, Threshold and Rotating
Edit contents of your scanned documents.
Export documents to common formats such as TXT, RTF, Searchable PDF and XLS.
NewSoft Presto! PageManager 7.23
Powerful document management software for OCR, PDF creation, or format conversion to Microsoft Word or Excel. TWAIN-Express makes it easy to connect with your scanner. Enhance images with a set of image tools such as crop, rotate, flip, invert color, auto-enhancement, brightness and contrast, color adjustment, and remove noise.
 Education – Administrative Offices
- Save general
business documents as PDFs
- Digitize student
records to comply with FERPA.
- Create electronic
copies of employment applications
- Digitize and email
paper documents to district offices and other administrators.
- Input paper
documents to student information systems.
- Create electronic
copies of student records.
- Email paper
documents to teachers, parents and administrators.
- Save an electronic
record of permission slips.
- Digitize and email
hand written meeting notes at the site of the meeting.
 Healthcare - Hospital In the paper world, when a patient checks in
with the front desk department, the receptionist has to leave his/her desk to
make photo copies for the patients' identifications and insurance cards. Staff
in hospitals and clinics are overwhelmed by diverse paper documents such as
insurance forms, patient documents, lab requests, referral letters, EOBs, etc.
The billing department staff rummage through paper files to find insurance
claims, denied claims or late payments from the healthcare payers.
Are those scenes familiar to you?
Appropriate deployment of scanning and imaging is essential to address
the paper-to-digital challenges in healthcare environments. Whether looking for
scanning solutions for the front desk, point of care, back office accounting
and patients' medical record management, Healthcare groups can choose from a
range of portable, mobile, workgroup, and departmental scanners from Plustek.
Plustek scanners, ranging from small sheetfed to desktop flatbed with
automatic document feeder, meet diverse card and document capture needs of the
healthcare industry. All Plustek scanners connect to notebook or desktop
computers via a USB port and are delivered with the industry standard TWAIN
drivers, offering easy integration and compatibility with your healthcare
software applications. As the leading global scanner manufacturer with two decades
of expertise in scanner hardware design and software/firmware development,
Plustek is able to deliver scanners featuring high throughput, functionality,
flexibility, reliability and competitive pricing.
Plustek scanners reduce registration time, automate
your data entry, improve data accuracy, speed up claim processing and meet the
compliance requirements (HIPAA, Sarbanes-Oxley, and others). Whether it
is an admissions process, patient records or a doctor's office environment,
Plustek scanners make short and easy work out of converting paper into digital
documents filing. Plustek healthcare solution scanners offer the optimal value
and performance.
Plustek's Patient Registration Desk and Mobile
Solutions for Quick Scanning Anytime, Anywhere
In the patient
registration area, Plustek scanners are used to scan and digitize: insurance
cards, driver's licenses, corporate ID cards, credit cards, business cards,
HIPAA forms, patient documents, payment checks, receipts, medical
prescriptions, claim documents, invoices.
This series of Plustek scanners feature small footprint and high
versatility. They fit neatly into your limited front desk space or a point of
care mobile cart. Workers are more productive because the scanners can easily
fit into their existing work environment. Their portability allows these
scanners to be used at the point of patient intake or patient care.
|
