Large Format Scanning
Large format scanning
of A3 size document (304.8 x 431.8 mm / 12” x 17”)
Fast scanning speed
Fast scanning speed
of 8.5 seconds for an A3 size color document at 300 dpi
Seven one-touch buttons
for performing pre-set functions enable the user to quickly: scan, file, copy, OCR, create PDFs and email.
User friendly bundled software
Bundled with simple-to-use image processing and document management tools, fast and secure PDF conversion, image organizer with thumbnail viewer, and accurate OCR software.
|Optical Resolution||1600 dpi|
|Scan Modes||Color: 48-bit input, 24-bit output|
Grayscale: 16-bit input, 8-bit output
B/W: 1-bit output
|Color Depth||Input 48-bit; Output 24-bit|
|Scanning Speed||8.5 sec (Color/ Grayscale/ B&W mode, 300dpi, A3) |
|Scanning Area (W x L)||Max. 304.8 mm x 431.8 mm (12" x 17"), A3|
|Daily Duty Scan ( Sheets )||2,500|
|Action Button||Scan, OCR, Copy, File, Email, Custom1 & Custom2|
|Power Supply||24 Vdc/ 2.08 A|
|Power Consumption||< 36 W (operation), < 4 W (idle)|
|Net Weight||7.5 Kgs (16.52 Lbs)|
|Dimensions (W x D x H)||623 x 400 x 133 mm (24.53” x 15.75” x 5.24”)|
|OS||Windows XP / Vista / 7 / 8 / 10|
Mac OS X 10.7.x/ 10.8.x/ 10.9.x/ 10.10.x
LINUX SANE only for Systems Integrator. Please contact local sales.
|Hardware Requirements||PentiumR IV 2.0 GHz processor|
One available USB 2.0 Port
512 MB RAM (1GB or higher recommended)
800 MB free HDD space (1 GB or larger recommended)
Button utility to simplify document scanning. DocAction enables you to specify your personalized scanning configuration settings and scan documents with the touch of a button. Scanned documents are automatically sent directly to Printer, Email, Folder or FTP. DocAction also enables you to scan directly to many imaging and document management applications. DocAction saves scanned documents in all common imaging formats including: JPEG, TIFF, and PDF.
Set your preferences of advanced functions of Removal Blank Page, Image Edge Fill and Remove Punch Holes.
ABBYY FineReader Sprint
Unlocks the data inside paper-based documents, images and PDF files with enhanced accuracy that eliminates the need for retyping and reformatting. Tool that increases your productivity and efficiency which comes with simple user interface and supports recognition up to 183 languages. Great features include:
- Convert scanned document and images into Microsoft Word, Excel, searchable PDF and other formats.
- Superior recognition accuracy & layout retention in 183 languages
- One-click smart conversion for easy access – no learning curve
- Multi-language recognition with automatic language detection
- Instant on-screen OCR and capture with bonus ABBYY Screenshot Reader
- State-of-the-art ADRT (Adaptive Document Recognition Technology) technology precisely preserves document formatting and style
NewSoft Presto! PageManager 9 SE
Presto! PageManager 9 is easy-to-use, front-end client software that handles all your documents. Capabilities include: capturing, previewing, converting, and delivering all your paper and electronic documents to a designated location. It lets you drag & drop to stack or merge files, or use the embedded Optical Character Recognition (OCR) feature to convert files to searchable PDF.
- Convert various document and image files to your favorite file formats, such as converting PDFs into fully formatted RTF, HTML, or Text.
- Create and edit PDF files - You can save or print document to PDF formats. Also able to merge and split PDF files.
- Use the Document Pallet - Simply drag files from one or more folders to convert them to a single PDF file and deliver it to an e-mail program or a printer in one step--without creating duplicate files.
- Manage your files in public cloud services at ease – Simply drag and drop files to DropBox, SkyDrive, Google Drive, Evernote or Facebook within PageManager after editing your files with notes, highlights, annotations, or converting files to searchable PDF.
The UNIVERISTY OF KANSAS
SCHOOL OF MEDICINE
ON SALINA CAMPUS GOES GREEN
WITH HELP FROM PLUSTEK’S ST BOOKSCAN CENTER
Plustek Helps Medical Campus
achieve its Goal to Go Digital
The University of Kansas School
of Medicine-Salina opened in July 2011 as an innovative medical education
program designed to address the shortage of rural doctors in the United States.
The goal of the program is to attract medical students with a strong interest
in practicing rural medicine and encourage them to stay and build their own
practices in rural areas after earning their degrees and completing their
residencies. The new campus’ curriculum is tied to the classroom offerings at
the KU Medical Center’s campuses in Kansas City and Wichita. The learning
process relies heavily on video-conferencing, with students in Salina
participating in lectures with their peers in other cities and receiving many
of their lectures via podcast.
To keep the program functioning
at its highest potential, Salina campus leaders decided that the best way to
streamline costs was to go green by using products such as scanners that are
more cost-effective than printers and reduce paper waste.
School administrators reviewed
their options and were leaning toward a large and expensive book scanner that
had been used with great success on another campus. Before deciding on
purchasing it, they were introduced to Plustek’s ST BookScan Center, which
offered features similar to the larger scanner but was more cost-effective.
Because of its size and price point, KU School of Medicine-Salina
administrators opted for the ST BookScan Center. They believed the ST BookScan
Center was a good match for the school’s highly computerized curriculum. School
administrators believe the medical students will find it more suited to the
electronic delivery of course materials than a traditional copier. 2
“We’re hosting a new generation of students who are much more
comfortable and tech-savvy than ever before, so I’m sure they will think of
endless ways to use the scanner in ways we haven’t even discovered,” said Lucy
Kolhoff, senior coordinator, KU School of Medicine, Salina campus. “Because of
the distance from the main school, our campus uses digital methods of
communication, so the ST BookScan Center works well with what we’ve been trying
to create, which is a highly accessible place to learn and retrieve information
Kolhoff is using the ST BookScan Center for archiving and digitizing documents
that are easily sent to the main campus. The scanner is located in an
accessible spot that allows medical students to readily scan library materials
to thumb drives and emails as well. Kolhoff believes that the Plustek ST
BookScan Center would be ideal for businesses and educational facilities that
rely heavily on paper and toner but want to go green. Kolhoff said that its
user-friendly software made the ST BookScan Center simple to understand and
easy to use.
alternative to the copier, the Plustek ST BookScan Center can scan books and
large format documents to a USB flash drive, shared network folder, FTP site,
email address or even a printer. The system is easy to use and does not require
user training. Prompts on the touch screen display guide users through the
scanning process and enable them to save books, bound materials and documents
in a variety of formats including searchable PDF. The ST BookScan Center was
created based on the concept of book preservation, digitization of content and
sharing of the book electronically. It can scan up to A3 size page (12” x 17”)
in just 2.4 seconds. Thanks to Plustek’s patent pending SEE technology, spine
shadows and distortions are eliminated and thick books are scanned without
unbinding or dismantling making it a perfect solution for digitizing precious
and valuable books and documents. The optional coin-op/card-op payment system
can be added for organizations that want to generate revenue from the use of
Accounting practices rely
on paper documents and processes. Paper documents are problematic for
your business because they must be manually filed, cause office clutter, are
difficult to find and share. As your practice grows, so does your pile of
paper documents and this causes you spend more time and money filing,
retrieving and sharing these documents.
Typical Accounting Documents
IRS tax forms
document scanners will help you organize and electronically file your paper
documents. Sharing documents with customers and colleagues becomes as
simple as loading documents and pressing a button. Imagine a clutter free
office with no stacks of paper! With a Plustek scanner, sharing and
organizing your documents is simple!
Easy to Use:
Plustek scanners feature DocAction single touch scanning. At
the touch of a button, you can save a document to any one of up to nine
different destinations including: folders on your PC or network, email, FTP or
even your printer. Thanks to the flexibility of DocAction and the
industry standard TWAIN drivers that are supplied with Plustek scanners, you
can scan directly into your accounting or document management application.
in image enhancement ensures the highest quality images with the least amount
of work. Documents are automatically adjusted for brightness,
automatically cropped to the proper size and rotated. The result is
higher OCR accuracy and fewer rescans.
Digitized documents can be saved in many different formats including:
searchable PDF, MS Office, TIF or JPG. You can scan tabular data and edit
it in Microsoft Excel. You can scan and edit a paper documents in
Microsoft Word and if you have standardized on PDF, you can save your documents
in either searchable PDF or image only PDF format.
Plustek scanners come with a software bundle that includes: Optical Character
Recognition (OCR), document management and business card reading software.
All Plustek scanners will create searchable PDF files with the touch of a
button. Searchable PDF files make your information easy to find and
share. Any desktop search software can be used to quickly locate
searchable PDF documents by searching by client name, tax ID number or any data
on your paper documents. No more miss filed documents! Another benefit
of using searchable PDF is document sharing. PDF files can be read on all
computer and mobile platforms including Windows, Mac, Unix, Linux, Android,
Windows Mobile, and Apple iOS (iPhone, iPad, iPod).
Plustek document scanners document scanner are designed with the image quality,
paper handling and reliability required by the most demanding business users
but at a price point attractive to small office and SOHO users. You can
easily cost justify a scanner for each member of your firm.
The Plustek EZ BookScan Center copies, scans
and prints ledger size -- making legal and archiving work effortless
Haydel has been a successful Deputy Clerk of Court in Franklin, Louisiana for
many years. Becky’s responsibilities include scanning and archiving all of the
original documents filed with the City for land pre servation purposes. The job
role requires her to ensure that all public documents and records are available
to the general public for review and copying in an ongoing and timely manner.
Her scanning duties become even more sensitive (and time intensive) when it comes
to scanning aged (and often bound) documents that are susceptible to damage
when scanning in the traditional fashion.
the Plustek EZ BookScan Center several times throughout the day to produce
copies of the original documents that have been bound into book volumes,”
explained Becky. “This Plustek GreenScan System saves me time because it allows
me to scan my next document page while the first page is printing.”
the courthouse had an old book copier that was modified by Binder Minder and
still worked, it would not allow them to copy up to the book’s binding. Adam
Crappel, of A & E Office Machines, Inc., spoke to Becky about a different
option. He introduced the idea of using the Plustek EZ BookScan Center which
consists of a Plustek OpticBook A300 scanner, kiosk-like software, and a
touch-screen computer, and printer that would operate similarly to their
original copier, but would provide more features. This solution proved more
efficient with better copy quality and ease, using touch screen display
allowing her to see the scanned document before it printed.
finds relief in a dedicated document and book scanning solution that is
convenient, efficient and produces quality images. The Plustek EZ BookScan
Center scans an A3-size page in just 2.4 seconds, creating a crisp, sharp
image, which can then be turned into different formats. The solution includes
highly effective image processing, fast and secure PDF conversion and highly
accurate optical character recognition (OCR) software. The scanned output can
be saved to a flash drive or shared network folder, sent to an email address,
printer or FTP site, Becky found these features in the Plustek EZ BookScan
Center more advantageous than the features in their previous photocopier/software
Plustek GreenScan System is very useful in producing excellent scanned copies
from our older bound records,” said Becky. “Producing quality images and saving
me time makes my job easier.”
Becky’s main responsibilities is assisting anyone doing research with the
court’s records. “Saving time on scanning documents has allowed me to give
assistance to those who need it, when they need it.”
Plustek EZ BookScan Center is an ideal solution for libraries, schools, graphic
designers, publishing companies, hospitals, law firms, court houses and
financial institutions. The Plustek EZ BookScan Center scans thick books
without unbinding or dismantling them, making it a perfect solution for
digitizing and preserving precious and valuable books. Particularly useful with
bound materials, the Plustek EZ BookScan Center also includes a patented design
that eliminates the book spine shadow and text distortion of traditional book
copying and scanning. Plustek’s patent-pending SEE? Technology (Shadow
Elimination Element) combines a patented lamp light with a special edge design
that allows the scanning module to scan right up to where the book spine is
placed. This clever design avoids the need for a large, expensive overhead
scanner or complicated image-editing software. With Plustek’s SEE? Technology
and the Plustek GreenScan System’s clearly-scanned pages, Becky is able to
produce perfect scan results, even near the binding.
latest edition to the Plustek product line is available from A & E Office
Machines, Inc and select Value Added Resellers nationwide. For more
information, call 714-670-7713 or email firstname.lastname@example.org
Tools & Applications
