Easy to use and no learning curve
The intelligent Plustek PL7500 ADF document scanner product with an improved TWAIN driver permits a simple scanning process just like photocopier; its auto detector function is capable of the scanning auto preview. |
|
Multifunctional scanning ability
With Auto Document Feeder (ADF) availability, PL7500 ADF scanner is capable of feeding 50 pages per time. The size ranges from 1.2 x 1.2 to 22 x 35.5 cm. Furthermore, with the same function as normal photocopier, the PL7500 ADF scanner also processes the flatbed operation. The perfect mechanical design of the PL7500 ADF scanner is for superior image focus and diminishing paper jam. |
 |
 |
High accuracy
With the Optical Character Recognition (OCR) software, PL7500 ADF document scanner yields results into a word processor with more accuracy. |
|
Environmentally Responsible and Energy-Saving
The SmartOffice PL7500 is ENERY STAR certified and environmentally responsible. |
 |
|
Features
The SmartOffice PL7500 has following features: |
|
|
● Auto Threshold
Automatically thresholds the current image into a binary black and white image.
|
 |
|
● Auto Rotate
Automatically rotates document based on the contents of the document.
|
 |
|
● Auto Crop & Deskew
Automatically straightens and crops image to the documents actual size.
|
 |
 |
● Color Dropout
Removes red, green or blue color when scanning forms. |
|
● Blank Page Removal
Automatically removes blank pages without manual editing. |
 |
| Optical Resolution | 600 dpi |
| Hardware Resolution | Flatbed: 600 x 600 dpi ADF: 600 x 600 dpi |
| ADF Capacity | 80 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs) Note: Maximum ADF capacity varies, depending upon paper weight. |
| Scanning Speed ( ADF ) | 75 ppm (Color mode, 200 dpi, A4 Portrait) 75 ppm (Grayscale mode, 200 dpi, A4 Portrait) 75 ppm (B&W mode, 200 dpi, A4 Portrait) Note : Results may vary depending upon your scanning application, computer processor and system memory. |
| Scanning Area (W x L) | Flatbed: Max. 216 x 297 mm (8.5" x 11.69") Min. 12.7 x 12.7 mm (0.5" x 0.5") ADF: Max. 216 x 356 mm (8.5" x 14") Min. 12.7 x 12.7 mm (0.5" x 0.5") |
| Acceptable Paper Sizes (W x L) | Flatbed: Max. 216 x 297 mm (8.5” x 11.69”) Min. 12.7 x 12.7 mm (0.5” x 0.5”) ADF: Max. 220 x 356 mm (8.66” x 14”) Min. 90 x 114 mm (3.55” x 4.5”) |
| Acceptable Paper Weight (Thickness) | 50 to 120 g/㎡ (14 to 32 Lbs) |
| Daily Duty Scan ( Sheets ) | 6,000 |
| Roller Lifetime (Scans) | 100,000 |
| Pad Lifetime (Scans) | 25,000 |
| Action Button | Custom 1, OCR, File, Scan, Copy, E-Mail, Custom 2 |
| Power Supply | 24 Vdc/ 1.67 A |
| Net Weight | 5.5 Kgs (12.1 Lbs) |
| Dimensions (W x D x H) | Without Input tray: 468 x 341.5 x 195 mm (18.43" x 13.44" x 7.68") With input tray: 468 x 341.5 x 320 mm (18.43" x 13.44" x 12.6") |
| OS | Windows 2000 / XP / Vista / 7 |
| Hardware Requirements | Pentium IV 2.0 GHz processor (Pentium IV 3.0 GHz processor recommended) CD-ROM Driver One available USB Port (USB 2.0 recommended) 1GB RAM or higher recommended 800 MB free HDD space (1 GB or larger recommended)
|
Plustek DI Capture
Image capture and management software featured with indexed archives. Makes it easy manage and organize documents and images efficiently. Exports files in PDF, JPEG, TXT and XLS with flexible file naming options.
Videos:
Plustek DocAction
Button utility to simplify document scanning. DocAction enables you to specify your personalized scanning configuration settings and scan documents with the touch of a button. Scanned documents are automatically sent directly to Printer, Email, Folder or FTP. DocAction also enables you to scan directly to many imaging and document management applications. DocAction saves scanned documents in all common imaging formats including: JPEG, TIFF, and PDF.
Videos:
Set your preferences of advanced functions of Removal Blank Page, Image Edge Fill and Remove Punch Holes.
I.R.I.S. Readiris 10 Pro Corporate
Award-winning photo/image management software supports over 100 popular applications, including color OCR and full-text indexing functions. Powerful document management software for OCR, PDF creation, or format conversion to Microsoft Word or Excel.
NewSoft Presto! PageManager 7.23
Powerful document management software for OCR, PDF creation, or format conversion to Microsoft Word or Excel. TWAIN-Express makes it easy to connect with your scanner. Enhance images with a set of image tools such as crop, rotate, flip, invert color, auto-enhancement, brightness and contrast, color adjustment, and remove noise.
 Education – Administrative Offices
- Save general
business documents as PDFs
- Digitize student
records to comply with FERPA.
- Create electronic
copies of employment applications
- Digitize and email
paper documents to district offices and other administrators.
- Input paper
documents to student information systems.
- Create electronic
copies of student records.
- Email paper
documents to teachers, parents and administrators.
- Save an electronic
record of permission slips.
- Digitize and email
hand written meeting notes at the site of the meeting.
 Healthcare - Hospital In the paper world, when a patient checks in
with the front desk department, the receptionist has to leave his/her desk to
make photo copies for the patients' identifications and insurance cards. Staff
in hospitals and clinics are overwhelmed by diverse paper documents such as
insurance forms, patient documents, lab requests, referral letters, EOBs, etc.
The billing department staff rummage through paper files to find insurance
claims, denied claims or late payments from the healthcare payers.
Are those scenes familiar to you?
Appropriate deployment of scanning and imaging is essential to address
the paper-to-digital challenges in healthcare environments. Whether looking for
scanning solutions for the front desk, point of care, back office accounting
and patients' medical record management, Healthcare groups can choose from a
range of portable, mobile, workgroup, and departmental scanners from Plustek.
Plustek scanners, ranging from small sheetfed to desktop flatbed with
automatic document feeder, meet diverse card and document capture needs of the
healthcare industry. All Plustek scanners connect to notebook or desktop
computers via a USB port and are delivered with the industry standard TWAIN
drivers, offering easy integration and compatibility with your healthcare
software applications. As the leading global scanner manufacturer with two decades
of expertise in scanner hardware design and software/firmware development,
Plustek is able to deliver scanners featuring high throughput, functionality,
flexibility, reliability and competitive pricing.
Plustek scanners reduce registration time, automate
your data entry, improve data accuracy, speed up claim processing and meet the
compliance requirements (HIPAA, Sarbanes-Oxley, and others). Whether it
is an admissions process, patient records or a doctor's office environment,
Plustek scanners make short and easy work out of converting paper into digital
documents filing. Plustek healthcare solution scanners offer the optimal value
and performance.
Plustek's Patient Registration Desk and Mobile
Solutions for Quick Scanning Anytime, Anywhere
In the patient
registration area, Plustek scanners are used to scan and digitize: insurance
cards, driver's licenses, corporate ID cards, credit cards, business cards,
HIPAA forms, patient documents, payment checks, receipts, medical
prescriptions, claim documents, invoices.
This series of Plustek scanners feature small footprint and high
versatility. They fit neatly into your limited front desk space or a point of
care mobile cart. Workers are more productive because the scanners can easily
fit into their existing work environment. Their portability allows these
scanners to be used at the point of patient intake or patient care.
|
